Description
GEM.03.G20 is a binocular zoom stereo gem microscope. It comes with a binocular head with widefield, high-eyepoint eyepieces and a gem stand. This microscope offers 6.7X-45X wide zoom power range and 100mm large working distance. It is an ideal stereo microscope for gem inspection.
Key Features
- Total Optical Magnification 6.7x~45x
- Professional jewelry microscope stand with base rotating and inclination adjustable
- Bright field transmit, reflect, polarizing and dark field observation
- Fluorescent bulb or LED (top) and transmitted (bottom) illumination system
- Fully coated optical system offering sharp and clear image
Specification
| Observation Ways | Bright field transmit, reflect, polarizing and dark field observation |
| Head | Binocular, 45° inclined, 360° rotatable, +/-5° diopter adjustable, interpupillary adjustment 54~75mm |
| Zoom Range | 0.67x~4.5x |
| Zoom Ratio | 1: 6.7 |
| Eyepiece | WF10x/22mm, both with eye-cup |
| Magnification | 6.7x~45x, up to 225x with auxiliary lens |
| Working Distance | 100mm, with standard 1x lens. Up to 26~287mm with auxiliary lens |
| Gem Clamp | Wire clamp for bigger objects, flat clamp for smaller objects |
| Stand | Professional jewelry microscope stand, with base rotating and inclination adjustable, with built-in dark field, polarizing device |
| Illumination | Top illumination 7w fluorescent or 1w led |
| Bottom transmitted illumination 6v 30w halogen lam |
Optional accessory
| Items | Specification |
| Eyepiece | WF10X/FN22, High-eyepoint, Wide Field with adjustable diopter, Dia:30mm(Micrometer mountable) |
| WF15X/FN16, High-eyepoint, Dia:30mm(Micrometer mountable) | |
| WF20X/FN12, High-eyepoint,12mm field of view, Dia: 30mm(Micrometer mountable) | |
| WF25X/FN9, High-eyepoint and wide field of View, Dia: 30mm. | |
| Objective | 0.3X, WD: 287mm |
| 0.4X, WD: 217mm | |
| 0.5X, WD: 177mm | |
| 0.75X, WD: 177mm | |
| 1.5X, WD: 47mm | |
| 2.0X, WD: 26mm |
Photo of this model is as following.
